Wir verändern die Art und Weise, wie Maschinen programmiert werden.
Legen Sie sofort los und beenden Sie die komplexe Fehlersuche.

Universell - einheitliche Struktur im Programm - einfache Bedienung der Maschine automatisiert umgesetzt.
Selmo Standard gewährleistet eine transparente Kommunikation zwischen Anwendern, Konstrukteuren und SPS-Programmierern. Gemeinsam setzen wir den Industriestandard um! Lesen Sie mehr über die Funktionen.
Ein Tool.
Ein Standard.
Ihr Prozess als digitales Modell.
Alle erforderlichen Funktionen für die Modellierung Ihres Prozesses, die Erstellung Ihrer Software, den Import und die Implementierung an einem Ort.
Logic Layer
Der Logic Layer wird verwendet, um die Schritte des Modells auf einer grafischen Oberfläche vorzumodellieren. Diese grafische Darstellung erleichtert die Modellierung des Prozesses erheblich.
.png)
System Layer
Das Programm wird in der Systemschicht modelliert, die Schritte und Zonen werden definiert und die Maschinenzustände und die Überwachung werden festgelegt.
.png)
Prozess modellieren
Der Prozess wird definiert und auf der Grundlage der erforderlichen Funktionalitäten in ein Modell umgewandelt. Es entsteht ein digitaler Zwilling Ihres Prozesses.
Bei der Modellierung verknüpfen Sie Prozesslogik und Baugruppen bitgesteuert. Die Ablauffunktionalität beschreibt eindeutig jeden Zustand Ihrer Maschine und Anlage.

PLC und HMI generieren
Aus dem Modell generiert ein Algorithmus den fehlerfreien SPS-Code (PLCopen XML) und die HMI - ohne weiteren manuellen Programmieraufwand. Alles mit geringer Code-Programmierung.

Das Zielsystem wählen
Wählen Sie das Zielsystem, in das Sie den SPS-Code exportieren möchten. Wir haben eine Reihe von Zielsystemen, die wir bereits unterstützen, und es kommen laufend weitere hinzu. Das Modell kann für jede PLC Open Hardware generiert werden.

Import - IBN - START
Nach der Generierung des Codes können Sie diesen im Zielsystem implementieren. Es muss nur noch der IO-Check durchgeführt werden, und das System kann mit der automatisch aus dem Modell generierten HMI gestartet und in Betrieb genommen werden. Virtuelle Inbetriebnahme und Software-Abnahmetest in einem Schritt.

Update verlauf
-
Aktuelle updates und fixes
Hier die Key-Features der neuen Version 2023.1:
- System Layer: Added operand “M” to monitor zone signals which are displayed in HMI and stored to alarm history database. This operand will not affect the automatic mode.
- System Layer: Added new zone type “Zone Mem”.
- System Layer: Added operand 'C' to set a zone as a cancel variable for a repeater.
- System Layer: Added possibility to show or hide all system zones at once and to switch zone header text between zone name and HMI display text.
- System Layer: Added possibility to filter zones by their group names.
- System Layer: Increased performance when connecting of large system layer to PLC, when a zone or group filter is applied.
- System Layer: Possibility to multiple edit of group name, HMI button and HMI button text of selected zones.
- Parameter Layer: Added feature to upload current values from PLC and to copy them to initial parameter value.
- Parameter Layer: Now the unit of the parameter is recognized when using type TIME and initial value."
- Parameter Layer: Removed for user useless parameter ID column.
- Selmo HMI: Added feature “Step decrement” and “Step next valid” to sequence controls in generated HMI."
- Selmo HMI: Fixed bug where too long step texts will not be wrapped.
- Selmo HMI: Now it's possible to start more than one instance of generated HMI's.
- Selmo Studio: Added new Target System “Beckhoff TwinCAT 3 OPC UA”.
- Selmo Studio: Added new Target System “CODESYS Control for PLCnext SL AXC Fx152”
- CMZ: Fixed bug at TCMZ layer where the error delay has no effect of generated PLC-Code.
- CMZ: Removed Auto-Reset column at TCMZ layer.
- CMZ: Removed for user useless CMZ ID column.
- Fixed bug in ctrlX WORKS licensing system.
- Fixed other many minor bugs and added some improvements
-
Vorhergehende updates und fixes
Hier die Key-Features der neuen Version 2022.9 SP2:
- System Layer: Fixed bug of broken PLC-Code when dissolving repeater and a cross sequence is also used in same sequence.
- CMZ: Fixed bug with special chars in variable name of TCMZ at hardware zone and plant level.
- PLC-Code Generator: Fixed bug in part of 'Start-Up Siren' generated PLC-Code which prevent the siren to work.
- PLC-Code Generator: Added Repeater Cancel Variable to input mapping program.
- Selmo HMI: Added possibility to parameters to hide from HMI panel.
- Selmo HMI: Fixed bug in OPC UA Controller when two variables have the same name.
- Selmo HMI: Fixed bug where disable switch not working at step monitoring when connected through OPC UA.
- App: Fixed Property Grid refreshing bug when switching between system layer tabs.
- App: Fixed wrong calculation of user zones + steps at license page.
- Fixed minor application bugs and added some other improvements.
Hier die Key-Features der neuen Version 2022.9 SP1:
- System Layer: Migrated zone operands to new characters 'S' for sequence-check and 'I' for interlock-check.
- System Layer: In-Out and Out zones can now be grouped. These grouped zones become a common group output in the IO GVL.
- System Layer: Zones which are attached to a driver will be now marked by an icon in the header row.
- Fixed minor application bugs and added some other improvements.
Hier die Key-Features der neuen Version 2022.9:
- System Layer: Added Feature 'Parameter Lists' to zone in- and outputs. Define individual analog values per step in a single in, out or in-out zone. You can also choose from a static value or from a sequence parameter for each step. You can find the parameter lists editor in the context menu of the sequence. To assign this list to a zone output you must first choose 'ParameterList' in the property 'Output Mode'. System Layer: Added Text-Filter for Zones to switch visibility.
- Selmo HMI: Introducing 'Language Switching' Feature. Translatable texts are reachable respectively editable over the corresponding context menu in the project explorer and the item 'Languages'. This is valid for all Selmo objects like steps, zones, parameters, CMZ, sequences, hardware zones and so on. Changing of the language can also be triggered by a global index-based language variable.
- Selmo HMI: Possibility to generate HMIs from a single sequence or hardware zone. Find these commands in context menu of corresponding item in Project Explorer.
- Selmo Standard: Interlock Stored bits will be reset now when reset from HMI or global executed.
- Selmo PLC Code Generator: Fixed bugs with specials characters during code generation.
- Logic Layer: Now it's possible to move diagram with middle mouse button.
- Logic Layer: Fixed problems and bugs with jumps and repeaters.
- System Layer: Fixed bugs when up- or downloading operands to an ADS driven controller.
- System Layer: minor bug fixes to UI.
- Selmo HMI: Added Logic Layer to HMI to show original diagram of sequence and the current active step.
- Selmo HMI: Added command 'HwZone Automatic Release' to hardware zone controls panel for releasing only sequences in this hardware zone.
- Application: Export the project documentation as a PDF-File with the command in the 'File' menu.
- Application: Activate or deactivate 'interlock stored' feature project-wide in the plant context menu.
- Application: Bosch Rexroth ctrlX WORKS licensing platform is now supported. From now it's possible to buy Selmo Studio licenses in the ctrlX store. Minimum version of ctrlX WORKS 1.14 is required.
- Application: Check for Selmo studio updates at start-up. When an update is available you can directly download it.
WIR HABEN DIE KOMPLEXITÄT IN DER PROGRAMMIERUNG ALLER MASCHINENZUSTÄNDE GELÖST, UND SO DIE GRENZE FÜR DEN MENSCHEN AUFGEHOBEN.
Pay-per-use
Kein Risiko. Keine Überraschungen.
Ein Selmo Tag für Euro 40.00 / in- output Signal. Angebote für Partner auf Anfrage.
WENN SIE ES MIT DER DIGITALISIERUNG ERNST MEINEN
Die Produktion ist jetzt viel effizienter
Mit unseren Selmo Services helfen wir Ihnen, die Möglichkeiten der Selmo Solution zu verstehen. Unser Team hilft Ihnen bei der Anwendung und der Integration in ihren Betrieb.
Ob durch Workshops, anfängliche oder vollständige Projektunterstützung, wir unterstützen Sie bei Ihren Automatisierungsbedürfnissen und machen Ihre Maschine auf die bestmögliche Weise digital nutzbar.
